| Print Technology |
Dye sublimation / resin thermal transfer |
| Print Resolution |
- Standard mode with Durable Graphics Module (DGM): 300 x 600, 300 x 1200, - Standard mode: 300 dots per inch (dpi) (300 X 600, 300 X 1200) standard text, bar code, and graphics printing
- TrueMatch™ printing technology. Ability to conform to ICC color workflow
|
| Print Speed |
- Single-sided color ribbon (YMCKT): up to 250 cards per hour (cph)
- Double-sided color ribbon (YMCKT-KT): up to 180 cards per hour (cph)
- Double-sided monochrome ribbon (black): up to 500 cards per hour (cph)
- 78 seconds to print color graphics and encode mag stripe
- 1 minute if using DGM
|
| Card Capacity |
- Input hopper: 125 cards (based on 0.03-in. card thickness)
- Output hopper: 25 cards
- Reject holding tray: 10 cards
- Front exception card slot
|
| Card Sizes |
Thickness: 0.027 - 0.033 inches for DGM |
| Card Materials |
- Card surface material and surface roughness can influence the print quality and durability of any thermal graphics printing
- For best results with durable graphics printing, use glossy PVC cards or glossy cards with PVC over laminate
- PVC cards or cards with PVC over laminate having average surface roughness (Ra) of 20 micro-inches (0.5 micron) or less, are also found to be suitable for use
- Other card types, such as PETG and varnished cards or cards with Ra greater than 20 micro-inches (0.5 micron), should be tested by the users for quality and durability before making their final selection
|
| DGM (Durable Graphics Module) |
Recommended for personalization (text). Good print = 5 point font; legible print = 4 point font |
| Operating Environment |
- Temperature: 60°F to 95°F (15°C to 35°C)
- Humidity: 20%-80% RH – non condensing
|
| Magnetic Stripe Encoding |
- ISO 7811 three-track support (high- and low-coercivity)
- JIS Type II single-track option
|
| Smart Card Personalization |
Contact and contactless smart card encoding for ISO 14443 A/B, ISO 15693, MIFARE® |
| MIFARE® DESFire® EV1/EV2 |
Single-wire connectivity | Supports production of EMV® level-1 compliant card |
| Specifications |
- TLS/SSL encryption, supports AES-256
- Bolt-down ready
- Secure cable lock (sold separately)
- Concealed output hopper
- Password-protected cabinet
- Non-resettable card counter for auditing
|
| Secure Ribbon Scramble |
- Printing with Secure Ribbon Scramble allows users to specify the card fields that are to be securely printed, making defined personal data difficult to read from the used ribbon supply
- Software needed: IFI On-prem 6.10 or higher and IFIaaS 8.3 or higher
- Available for UV monochrome ribbons (excluding cassette types) and standard (ISEGA) black and white non-UV ribbons
- Only recommended for personalization fields, not recommended for non-personalization information
|
| LCD Display Languages |
English, Spanish, German, Italian, and Japanese |
| Physical Dimensions |
- Sigma DS4 + Durable Graphics Module: L 26.15 in x W 8.9 in x H 9.6 in
- Sigma DS4 Multi-hopper + Durable Graphics Module: L 26.15 in x W 13.4 in x H 16.2 in
- Sigma DS4-ES1 + Durable Graphics Module: L 35.5 in x W 14 in x H 19.75 in
- Sigma DS4-ES1 Multi-hopper + Durable Graphics Module: L 35.5 in x W 14 in x H 27 in
|
| Weight |
- Printer: 12.1 lbs
- Printer with DGM: 22.1 lbs
- Printer with DGM and Multi-Hopper: 40.9 lbs
|
| Connectivity |
Ethernet |
| Driver Operating System Support |
Supported by Instant Financial Issuance Software 6.7 (On-prem) and 8.2 (as a Service) |
| Warranties |
36 months |
